1、Product parameters
PRODUCT MODEL | supply voltage | Input power | output current | Product sizeLxWxH(mm) |
INVCT301 |
380VAC 50/60Hz 415VAC 50/60Hz |
20kW | 40A | 335 x 245 x 157 |
INVCT302 | 28kW | 50A |
2、characteristic:
Universalization:Covering a power range of 16-24HP, different compressors can be easily configured by dialing codes.
3、High reliability:
①Dual switch topology structure:Easily achieve standby power consumption<5W, meeting customers' energy-saving needs while extending the service life of capacitors;
②Compressor exhaust high pressure hardware protection:The compressor discharge is linked with the busbar relay to ensure the safety of the unit under extreme conditions;
③Three phase imbalance handling mechanism:Ensure reliable operation even under harsh grid quality conditions, with no degradation in service life;
④Pollution Level III+Full Coating:Ensure the reliable operation of products in harsh polluted environments;
⑤Double 85 and strife test:Comprehensive and multi-dimensional (voltage, temperature, and load) rigorous testing to ensure the normal operation of the product under extreme working conditions;
⑥Professional PCBA OEM factory:Ensure more reliable production quality of delivered products.
